Laser cutting pattern for a nut basket

Categories: download file, Corel file, Laser box design

Description
Reviews (0)

Explanation:

Specs	Amount / Info
Software	CorelDRAW version 15 or higher
Material usage	About 4 units of this design fit on a 90 × 120 cm sheet
Top circle diameter	23 cm
Bottom circle diameter	17 cm
Height	9 cm
Basket depth	7 cm
File formats	CDR - DXF - DWG
Material thickness	3mm MDF
Compatible machines	Non-metal laser cutters, CNC machines, marquetry cutting machines
Usable surfaces	Common materials like MDF, plexiglass, aluminum, copper (3mm thick)

Please get a bit more material than the size mentioned.

Assembly tutorial video: https://aparat.com/v/f8CmS

Laser cutting guide:

Black lines are for full cuts
Blue lines are for scoring
Green lines are for engraving

Corel pattern file:

The pattern is designed with CorelDRAW and AutoCAD, and it's fully editable.
For those who aren’t familiar with CorelDRAW or AutoCAD, there’s also a DXF file in the folder. You can just hand it over to the laser operator, and they’ll be able to cut it easily without needing to arrange the pieces themselves.
